2000 Durango - Gear Indicator out

Hello everyone,

I just purchased a 2000 Durango, and noticed that the digital gear indicator does not light up most of the time (the letters and the box around the selected gear). Occasionally when parked or in the middle of a drive, it may come on for a minute or so but more often than not, it does not light up. When it does light up, whichever gear I am in, or shifting through, is accurately selected. The digital odometer lights up, and all of the lights for the other non-digital gauges are functioning.

Has anyone had this problem before, or know how this could be fixed?

Thank you!
Reply With Quote Quick reply to this message
Sponsored Links
Advertisement

  #2
Old 07-13-2012, 07:21 AM
TazRango's Avatar
TazRango TazRango is offline
Jersey Boy



Join Date: Dec 2007
Location: Kansas
Vehicle: 2000 Durango SLT+ 4.7
Posts: 8,252
Reputation: 175 TazRango is a name known to allTazRango is a name known to all
The whole indicator goes out? Or does the PRND21 show up but the indicator box does not?

If the PRND21 is there but the indicator is not, then it's either a bad sensor in the transmission or a loose/bad connector. If the whole thing isn't lighting up and it comes on randomly, it could be a broken solder connection or failing component on the cluster circuit board.

There is no separate fuse for that display - however, it does get its data feed from a separate computer (the TCM). So if the PRND21 is there just with no box, it's also possible the TCM is failing or losing power. Does the transmission shift properly through all four gears? Do you have any codes? Is the Check Engine light on? You can check for codes by turning the key (starting at OFF) ON-OFF-ON-OFF-ON (landing at ON) and watch the odometer. It will flash out P codes separated by ------. At the end (or if there are no codes) it will say PdonE.
__________________


Quote:
"Ever had one of those days where you want to light someone's face on fire and try to put it out with a fork?"
Quote:
Originally Posted by Big_Texxan View Post
fuck it, Im going to convert those to HID and stick them in my heads, fogs, tails, double heads, and my butt so I make a halo while shitting

It would be like a holy shit, and maybe one around my penis for that illuminating experience a girl has hahahaahahahaah
Quote:
"Through this inscription I wish to enter my dying protest against what is called the Democratic party. I have watched it closely since the days of Jackson, and know that all the misfortunes of our nation has come to it though this so-called party. Therefore beware this party of TREASON." -Nathaniel Grigsby (1890)
Quote:
"How many times is Biden gonna say something stupid?" -Barack Obama (378 gaffes and counting!)
Reply With Quote Quick reply to this message
  #3
Old 07-13-2012, 03:21 PM
Intense2000's Avatar
Intense2000 Intense2000 is offline
Registered User

Join Date: Jan 2012
Location: Dushore, PA
Vehicle: 2000 Dakota
Posts: 1,465
Reputation: 22 Intense2000 is just getting started
Garage
Send a message via AIM to Intense2000
My truck does the from time to time. It's usually either neutral or sometimes reverse. Quite often it does it when I put it in 1 because I live on a terrible road and this makes going slow downhill easy. Also my O/D OFF light comes on when I'm accelerating hard 99% of the time, but O/D is still on. The indicator lights have been doing that since I got it. The O/D OFF thing didn't start until the Superchips install. It's also kinda rough about shifting into reverse, and there is no interlock/block off for reverse or park. No codes though....
__________________
2000 DODGE DAKOTA 4.7 V8 * 45RFE * 3.55 LSD

REFLEXXIONS COWL * GRABBER AT2S * K&N FIPK2 * SUPERCHIPS 3715 * MOPAR TCM * CATBACK DUALS
Reply With Quote Quick reply to this message
  #4
Old 07-13-2012, 09:51 PM
mike407 mike407 is offline
Registered User

Join Date: Jul 2012
Location: NYC
Vehicle: 2000 Dodge Durango
Posts: 2
Reputation: 10 mike407 is just getting started
Quote:
Originally Posted by TazRango View Post
The whole indicator goes out? Or does the PRND21 show up but the indicator box does not?

If the PRND21 is there but the indicator is not, then it's either a bad sensor in the transmission or a loose/bad connector. If the whole thing isn't lighting up and it comes on randomly, it could be a broken solder connection or failing component on the cluster circuit board.

There is no separate fuse for that display - however, it does get its data feed from a separate computer (the TCM). So if the PRND21 is there just with no box, it's also possible the TCM is failing or losing power. Does the transmission shift properly through all four gears? Do you have any codes? Is the Check Engine light on? You can check for codes by turning the key (starting at OFF) ON-OFF-ON-OFF-ON (landing at ON) and watch the odometer. It will flash out P codes separated by ------. At the end (or if there are no codes) it will say PdonE.
The PRND21 and the selector box is, most of the time, completely off. Not just the selector box - it's the whole display. Once in a while it will come on, either mid-drive or when I first start the truck and will accurately reflect the gear I am in. But most of the time it isn't on.

The transmission shifts properly through all gears and the check engine light is off. No other irregular displays are on. I tried the key-turning method you told me to try to get pcodes. It simply showed the mileage, the three dashes (---), then Pdone. Nothing between.
Reply With Quote Quick reply to this message
  #5
Old 07-14-2012, 09:36 PM
TazRango's Avatar
TazRango TazRango is offline
Jersey Boy



Join Date: Dec 2007
Location: Kansas
Vehicle: 2000 Durango SLT+ 4.7
Posts: 8,252
Reputation: 175 TazRango is a name known to allTazRango is a name known to all
Yeah then I think it's a safe bet that it's an issue with the cluster. Do you notice that it comes on after you hit a bump/rough patch/if you hit it? Or is it completely random? Rough patch indicates a broken solder connection, which is relatively easy to fix - once you find it. Completely random indicates an electronic problem, which in the absence of special tools, a schematic and test point values will be next to impossible to fix.
